Description
Dimension:
105*80*25(H)mm (not include the height of water outlet)
Description:
aluminium heatsink, 17-20 fins per inch
8 microchannel design
SealingTechnology: vacuum brazing of aluminium
Suitable for 80mm fan, screw hole size: 69.5mm*69.5mm
Color and heat exchange efficiency could be custom made.
Suitable for liquid cooler system for CPU of computer, Industrical frequency conversion driver, laser head, air conditioning evaporator and industrial control cabinet
Specification:
Model: R80A microchannel water cooler
Materials: aluminium
Dimension: 105*80*25(H)mm
N.W.: 180g
Density of fin: 17 fins/inch
Qty of tube: 8 tubes
SealingTechnology: vacuum brazing of aluminium
Surface treatment: environmentally friendly black lacquer
external diameter of water outlet: Φ9.5mm
water pipe: apply to internal diameter Φ6-8mm Silicon pipe with clip
